Operated by a reliable PLC control system with digital and optional analog outputs for remote monitoring and alarm capabilities.
Provides the operator with continuous indication of column A, column B, inlet air & nitrogen outlet pressures and features an easy-to-operate touch screen graphical human-machine interface (HMI) which offers valuable information including:
Power On Off
Oxygen Purity
Inlet & Outlet Pressure
Online Column
Service Required
Run Hours
Communication
Standard communication protocols include Modbus TCP communications via RJ45 ethernet port and 4-20 mA signal to monitor nitrogen purity.
An upgradable SD card records the performance of the generator and data that can be downloaded to any PC for analysis.
Purity Dependent Energy Saving (PDES)
With the optional employment of 2 oxygen analyzers, the PDES option allows additional energy saving to be attained by keeping the purity within a narrow band of the required value.
Achieved by elongating the adsorption cycle and consequently saving valuable compressed air
Features
Ultra compact design and wide range of flow rates, make it the perfect generator for a variety of lower flow nitrogen applications.
Significant cost savings over cylinder or liquid supply provides a typical return on investment of less than 24 months.
Uses pressure swing adsorption to produce a continuous, uninterrupted supply of 95 to 99.999% purity nitrogen gas from clean, dry compressed air.
100% functional tested with 2 year warranty.
Eliminates safety concerns associated with transporting and storing pressurized gas cylinders or liquid nitrogen.
Reduces carbon footprint by eliminating gas delivery with positive impacts on sustainability targets.
eco-mode energy savings control reduces energy consumption during periods of low demand.
Optional integrated O2 analyzer and dew point sensors (N2 or inlet air).
