RTi Expert Air Systems
RTi Product Lines
Eliminex Series
Eliminex Mainline Separator
- Removes water & dirt to 3.0 micron
- Available in 1/2" NPT- 6" ASA (150#) Flange
- Available 60-5500 scfm @ 100 PSI
Eliminex Mainline Separator Combo
- Removes water, dirt & oil up to 0.01 micron
- Available in 1/2" NPT - 6" ASA (150#) Flange
- Available 60-3000 scfm @ 100 PSI
Eliminex Series
Eliminizer Mainline Separator
- Removes water and dirt up to 1.0 micron
- Available in 1/4"- 1" sizes
- Available 20-150 scfm @ 100 PSI
Eliminizer Combo Mainline Separator Combo
- Removes water, dirt & oil up 0.01 micron
- Available in 1/4"- 1" sizes
- Available 20-150 scfm @ 100 PSI
Coalescers
Coalescers
- Removes dirt and oil up to 0.01 micron
- Available in 1/4" NPT - 6" ASA (150#) flange sizes
- Available in 60-3000 scfm @ 100 PSI
Oil Extractors
Oil Extractor
- Removes water, dirt & oil vapor up to 1.0 micron
- Available in 1/2" - 1" sizes
- Available in 60-150 scfm @ 100 PSI
Oil Extractor Combo
- Removes water, dirt, oil & oil vapor up to 0.01 micron/0.003 ppm
- Available in 1/2" - 1" sizes
- Available in 60-150 scfm @ 100 PSI
Desiccant Dryer
Eliminator II Desiccant Dryer
- Lowers dew point to -40ºF
- Removes water, dirt and light oil
- Handles up to 30 scfm
- True moisture indicator downstream
- Available in 1/4", 3/8" & 1/2" NPT Port Size
- 1/4" Regulator & Gauge Optional
Desiccant Systems
DRAD Regenerative Desiccant Systems
- Lowers dew point to -40ºF or -100ºF (optional)
- Simple, effecient, with only 2 moving parts
- 4-30 scfm outlet @ 100 PSI available
Refrigerated Dryers & Compressors
Dryers & Compressors
- Energy efficient cycling dryers reduce costs up to 80%; Compact, low maintenance
- Rotary screw & piston compressors available 5-300 HP, long lasting, easy to service
Regulators
Regulators & Heavy Duty Regulators
- Different sizes and styles to meet your needs.
Lubricators
Lubricators & Heavy Duty Lubricators
- Different sizes and styles to meet your needs.
High Pressure Products
Food Grade, 316 Stainless Steel, High Pressure Products
- Meet the needs of the food industry where FDA specs must be followed.
- 316 SS construction available in 60, 90 & 150 scfm
- High pressure units are perfect for natural gas applications
Eliminizer® 20 Standard Cubic Feet per Minute (scfm) Point-of-Use Dryers/Filters
RTi’s patented Inverse-Flow® filter-dryer with two (2) stage filter packing: stainless steel mesh and cotton/polyester. Excellent water and dirt capture to 1 micron. ISO Class 2 for Particulate.
Eliminizer® 35/60 Standard Cubic Feet per Minute (scfm) Point-of-Use Dryers/Filters
RTi’s patented Inverse-Flow® filter-dryer with two (2) stage filter packing: stainless steel mesh and cotton/polyester. Excellent water and dirt capture to 1 micron. ISO Class 2 for Particulate.
Eliminizer® 90/150 Standard Cubic Feet per Minute (scfm) Point-of-Use Dryers/Filters
RTi’s patented Inverse-Flow® filter-dryer with two (2) stage filter packing: stainless steel mesh and cotton/polyester. Excellent water and dirt capture to 1 micron. ISO Class 2 for Particulate.
Eliminizer® 20 Standard Cubic Feet per Minute (scfm) Combo Point-of-Use Dryers/Filters
Two (2) stage assembly which combines an Eliminizer® filter-dryer with a high efficiency coalescer to give superior oil and fine particulate capture, in addition to heavy water removal. 99.99998 % efficient at 0.01 micron. ISO Class 1 for Particulate/Oil.
Eliminizer® 60 Standard Cubic Feet per Minute (scfm) Combo Point-of-Use Dryers/Filters
Two (2) stage assembly which combines an Eliminizer® filter-dryer with a high efficiency coalescer to give superior oil and fine particulate capture, in addition to heavy water removal. 99.99998 % efficient at 0.01 micron. ISO Class 1 for Particulate/Oil.
Eliminizer® 90/150 Standard Cubic Feet per Minute (scfm) Combo Point-of-Use Dryers/Filters
Two (2) stage assembly which combines an Eliminizer® filter-dryer with a high efficiency coalescer to give superior oil and fine particulate capture, in addition to heavy water removal. 99.99998 % efficient at 0.01 micron. ISO Class 1 for Particulate/Oil.
Eliminizer® 60/90/150 Standard Cubic Feet per Minute (scfm) High Flow Food Grade Separators
RTi's patented Inverse-Flow® filter-dryer with two (2) stage filter packing: stainless steel mesh and cotton/polyester. Excellent water and dirt capture to 1 micron. ISO Class 2 for Particulate.
Food Grade certified non-toxic powder coated filters meet requirements of 21 CFR 100. Coating ingredients meet at least one section of FDA Title 21, with the exception of food items containing 8 % alcohol.
Eliminizer® 60/90/150 Standard Cubic Feet per Minute (scfm) Combo High Flow Food Grade Separators
Two (2) stage assembly which combines an Eliminizer® filter-dryer with a high efficiency coalescer to give superior oil and fine particulate capture, in addition to heavy water removal. 99.99998 % efficient at 0.01 micron. ISO Class 1 for Particulate/Oil.
Food Grade certified non-toxic powder coated filters meet requirements of 21 CFR 100. Coating ingredients meet at least one section of FDA Title 21, with the exception of food items containing 8 % alcohol.
Eliminizer® 60/90/150 Standard Cubic Feet per Minute (scfm) 316 Stainless Steel High Flow Separators
Two (2) stage assembly which combines an Eliminizer® filter-dryer with a high efficiency coalescer to give superior oil and fine particulate capture, in addition to heavy water removal. 99.99998 % efficient at 0.01 micron. ISO Class 1 for Particulate/Oil.
